• 【4MP High-Definition Camera】Equipped with a 4MP high-definition lens and dual-light night vision for clear monitoring day and night.
• 【5-inch HD Touchscreen】Features a 5-inch high-definition touchscreen monitor with a built-in 5200mAh large-capacity lithium battery.
• 【Solar Powered & WiFi 6】Supports solar charging for operation and WiFi 6 for faster, more stable wireless connections.
• 【Two-Way Audio】Enables real-time communication with visitors, even when offline through local network functionality.
• 【Flexible Installation】Compatible with multiple doorbell models and includes a desktop stand for versatile placement options.
• 【Remote Viewing】Access real-time footage through the mobile app and expand local storage up to 256GB.
• 【Multi-Device Support】Connects with up to 4 battery-powered cameras simultaneously for comprehensive home security.

Specifications:

• System:
• Main processor: 1GHz clock speed, 1.5TB high-performance SOC
• Operating system: Linux
• Display: 5-inch
• Resolution: 720 x RGB x 1280
• Touchscreen: Not supported
• Screen off: Automatically turns off when exiting the configuration interface
• Video:
• Encoding format: H.264
• Maximum resolution: 4 channels, 1920 x 1080
• Terminal interconnected wireless doorbell (DH002) & battery camera (DH005)
• Low-power doorbell: Supported (standard)
• Battery camera: Supported (optional)
• Connection method: WiFi: The doorbell or battery camera scans the host's QR code to pair and connect to the host's WiFi
• Number of terminals: Supports up to 4 terminals, battery cameras
• Terminal:
• Type: Low-power battery video doorbell/camera
• Pixels and resolution: 4M (1920 x 1440)
• Batteries: 2 x 18650 batteries (5200mA)
• Rechargeable: Supports rechargeable/5V 1.5A charger
• Encoding: H.264
• PIR: Support time is configurable, default is off.
• Standby current/standby time: <1mA/over 3 months
• Doorbell button: Supported
• Pairing method: Scan the channel QR code on the host or the channel management QR code in the app
• Audio: Two-way voice
• Protocol: G711
• Speaker: Built-in 1W speaker
• Microphone: Built-in microphone
• Function: Supports two-way voice, simplex
• WiFi:
• WiFi type: WiFi 6
• Standards: IEEE 802.11b/g/n/ax 1T1R
• Security protocols: WPA, WPA2, WPA3 personal
• Operating frequency: 2.412-2.484GHz
• Operation Panel:
• Keyboard: Soft keyboard/Shift key toggles uppercase and lowercase
• Function buttons: Silicone rubber keys
• Local Storage:
• TF card storage: Supports 128GB
• Recording standard: MP4
• Recording mode: Event recording (e.g., a visitor rings the doorbell, activating the PIR wakes up the camera)
• Recording resolution: VGA
• Recording playback: App playback
• Notifications:
• Doorbell visitor: Real-time video push notification and support for real-time intercom
• App notifications Visitor and PIR events can be notified to users via the app.
• Alert sound: Doorbell ding-dong notification.
• Application Scenarios:
• Video doorbell: Receive real-time video feeds to the indoor host upon doorbell ringing, providing premium protection for your family.
• Security system: A wire-free, portable security system allows security personnel to monitor surrounding conditions at all times.
• Home surveillance kit: Equipped with a low-power battery-powered camera, eliminating the hassle of wiring.
• Office visitor system: Convenient for selective visitor access.
• Others:
• Power connector: Type C.
• Operating temperature: -10°C to 50°C
• Power consumption: 4.5W to 7.5W
• Operating humidity: 10% to 90% RH

Package included

• 1 x Doorbell
• 1 x Camera
• 1 x Main Unit
• 3 x Charging Cables
• 1 x Solar Panel
• 1 x Power Adapter
• 1 x Doorbell Backplate and Sticker
• 1 x Installation Screw Pack
• 1 x English and Chinese User Manual
